Industrial computers are industrial control computers specially designed for industrial use. Their basic performance and compatibility are similar to those of commercial computers, but industrial computers pay more attention to stability in different environments. Hystou industrial computers have excellent stability and can adapt to the requirements of various industrial production environments.

Processor parameter for referance only:

1. Intel Core i5-7267U 2 cores 4 threads 3.1GHz up to 3.5GHz 4MB cache TDP 28W Intel Iris Plus Graphics 650.

2. Intel Core i5-8250U 4 cores 8 threads 1.6GHz up to 3.4GHz 6MB cache TDP 15W Intel UHD Graphics 620.

3. Intel Core i7-8550U 4 cores 8 threads 1.8GHz up to 4.0GHz 8MB cache TDP 15W Intel UHD Graphics 620.

4. Intel Core i5-10210U 4 cores 8 threads 1.6GHz up to 4.2GHz 6MB cache TDP 15W Intel UHD Graphics.

5. Intel Core i7-10510U 4 cores 8 threads 1.8GHz up to 4.9GHz 8MB cache TDP 15W Intel UHD Graphics.

- Fanless system without cooling fan, no any noise, thicker and longer heat-sink fins for working as long as 7x24 hours durably.

- Brushed Full Aluminum Alloy Silver/Black color shell for heat dissipation, Exquisite production craft on outside design.

- 2xIntel i201/i211 Gigabit RJ45 LANs, 6xDB9 COM(4xRS232/422/485), 8xUSB(2xUSB inside), PS/2, GPIO and LPT rich ports for different equipments.

-3xStorage: 1*MSATA SSD+1*M.2 NVME SSD+1*2.5''SATA installation together;

- Fit for 9-36V 3pin phoenix terminal power input, ATX/AT quick switch.

- Support VGA + HDMI dual display output synchronously.

- One embedded SIM card slot onboard for 3G/4G Wi-Fi.

- Support Watchdog, AWAL, RTC, WOL(ATX mode), PXE, Reset functions.

- Low consumption TDP only 10W and can be mounted on the wall.
